ETFE SPR-F 165W 27V marine solar cell flexible
Technical properties of the ETFE SPR-F 165W solar module
165W nominal power at an operating voltage of 27.3V and a current of 6.05A
walkable and even more slip-resistant than comparable solar modules on the market, even when wet
2 bypass diodes – minimized power loss in shaded conditions
semi-flexible – bendable up to a maximum of 30 degrees (long side)
easy installation of the solar panel by gluing or using the ring eyelets
specially developed for long-term marine use
ETFE high-tech plastic ensures weight savings and high light transmission of up to 96%
Junction box with IP65 protection
easy installation thanks to pre-assembled solar cable with MC4 plug and socket
small dimensions (LxWxH): 1460 x 540 x 2 mm
Solar panel can be mounted by gluing or using the ring nuts
Manufacturer part number (MPN): 010905
low weight: only 3 kg
proven Offgridtec quality: manufactured exclusively from premium raw materials of the highest quality
The ETFE SPR-F 165W is a semi-flexible high-performance solar cell that is ideally suited both as a solar module for motorhomes and specifically for marine use on sailing yachts, motor yachts, and other types of boats
The module is ideal for 12V system voltage in conjunction with an MPPT charge controller. The ETFE 165W 12V solar cell is semi-flexible and can be walked on when mounted completely flat.
| Βάρος | 2 κ. |
|---|---|
| Διαστάσεις | 1350 × 660 × 2 cm |
